Increased water usage, wash down water and process water. Pioneer understands that water is a critical resource for wineries.
Wineries across Australia have large roof catchment areas provided by their buildings and sheds.
Many owners have discovered the benefits of harvesting clean fresh water from their gigantic roofs. Do you need extra water to wash down equipment and floors without having to pay for it?
Pioneer has the perfect quality solution.
Pioneer Water Tanks have supported the wine and viticulture industry for over 30 years.
Pioneer Water Tanks are based just outside of the Swan Valley, and only a short drive to the Chittering Valley and Margaret River wine regions.
This means we have plenty of experience in providing durable and reliable high performance water storage products to wineries and vineyards.
Pioneer Water Tanks can be used for all your water supply requirements for your vineyard or winery.
Pioneer Water Tanks winery uses:
A feat of engineering excellence, the Pioneer V-LOCK® wall profile is designed to stand the test of time and provides superior internal support for the tank liner.
The AQUALINER Fresh® antimicrobial tank liner is designed keep your water fresher, cleaner and healthier for longer.
Pioneer Water Tanks are offered in a variety of sizes to achieve your water storage goals.
The Litres/Gallons stated in the table are gross capacities.
Actual useable volume will vary depending on the size and position of inlets and outlets.
MODEL | Diameter | Height | Litres | Gallons |
|---|---|---|---|---|
GT10 | 2.67m | 2.18m | 12,200 | 2,600 |
GT20 | 3.34m | 2.18m | 19,100 | 4,200 |
GT30 | 4.01m | 2.18m | 27,542 | 6,053 |
GT40 | 4.68m | 2.18m | 37,574 | 8,258 |
GT50 | 5.35m | 2.18m | 48,963 | 10,761 |
GT60 | 6.02m | 2.18m | 62,111 | 13,651 |
GT80 | 6.69m | 2.18m | 76,504 | 16,814 |
GT90 | 7.35m | 2.18m | 92,570 | 20,345 |
GT110 | 8.02m | 2.18m | 110,116 | 24,212 |
GT130 | 8.69m | 2.18m | 129,292 | 28,416 |
GT150 | 9.36m | 2.18m | 149,948 | 32,956 |
GT170 | 10.03m | 2.18m | 172,134 | 37,832 |
GT200 | 10.70m | 2.18m | 195,851 | 43,044 |
GT220 | 11.36m | 2.18m | 221,604 | 48,704 |
GT250 | 12.03m | 2.18m | 247,874 | 54,478 |
GT280 | 12.70m | 2.18m | 276,180 | 60,751 |
GTi291 | 10.70m | 3.23m | 290,632 | 63,876 |
GTi328 | 11.36m | 3.23m | 328,096 | 72,109 |
GTi328 | 12.03m | 3.23m | 367,831 | 80,784 |
GTi410 | 12.70m | 3.23m | 409,860 | 90,157 |
GTi454 | 13.37m | 3.23m | 454,112 | 99,891 |
GTi501 | 14.04m | 3.23m | 500,065 | 500,065 |
At Pioneer, we’ve been designing and manufacturing rural water tanks for over 30 years, and we’re so confident in their durability that all of our tanks come with our exclusive Pioneer 20/20 warranty.
That means a 20-year conditional structural warranty, in addition to a 20-year conditional warranty gainst water leakage (only applicable for tank models GT10—GT280.)
With Pioneer’s Dealer Direct® Network of over 50 distributors all across the country, you can rest assured that you will be dealing with the knowledge and experience of a local family business.
Whether your water tank is for your home farm or holiday property, it needs to be in keeping with your personal aesthetic, Pioneer Water Tanks has a range of colours and additional features to choose from.
Yes. Our water tanks are manufactured and built for all sorts of applications and they can handle the demand of a winery or vineyard.
If you are taking water from a dam or bore to irrigate your vineyard, we recommend (where possible) that you install your inlet at the bottom wall of your water tank.
It might seem unusual but the best water tank performance comes from bottom inlets. If you water is coming from a roof we recommend the standard roof leaf filter basket.
Yes. We can provide you with a water tank that has facilities ready to take on water from most water sources.
Top inlets create tiny wave actions on the water service when water enters the tank and sometimes water can splash into the roof area. If you can, you should avoid this.
When you fill from a bottom inlet you should be pushing into a volume of water, water levels simply rise and fall, and there’s no splashing.
You might be thinking there’s a lot of water inside pushing back into your inlet, that’s not the case.
When you send water to the top of a two-metre water tank you have two metres of head pressure. With this in mind, if the water level inside your tank is sitting at one metre you have one metre of head pressure, two metres equals two metres of head pressure and so on.
We provide a full suite of features; AQUALINER FRESH® tank liner, double fusion-welded liner seams, adaptive swivel foot roof truss connector, roof access hatch, external hook on ladder, 80mm overflow, 80mm outlet and valve (multiple if required), and 50mm inlet.
